Building.modern(DSLs).with(Groovy)

by Cédric Champeau (@CedricChampeau), Gradle Inc.

Who am I

speaker {
    name 'Cédric Champeau'
    company 'Gradle Inc'
    oss 'Apache Groovy committer',
    successes 'Static type checker',
                    'Static compilation',
                    'Traits',
                    'Markup template engine',
                    'DSLs'
        failures Stream.of(bugs),
        twitter '@CedricChampeau',
        github 'melix',
        extraDescription '''Groovy in Action 2 co-author
Misc OSS contribs (Gradle plugins, deck2pdf, jlangdetect, ...)'''
}
GradleLogoReg

Disclaimer

This is an opiniated talk about how a DSL designed with Apache Groovy should look like.

terminator

Domain Specific Languages

  • Focused

  • Readable

  • Practical

  • (usually) embeddable

  • Examples: SQL, HTML, XSLT, Ant, …​

Apache Groovy for DSLs

  • Concise, clean syntax

  • Supports scripting

  • Supports metaprogramming

  • Embeddable

  • Mature tooling: Eclipse, IntelliJ, Netbeans…​

Some old Groovy DSLs

IntelliJ IDEA’s GDSL

contributor(context()) {
  if (classType?.hasAnnotation("groovy.lang.Singleton")) {
    property name: "instance",
             type: classType?.getQualifiedName() ?: "java.lang.Object",
             isStatic: true
  }
}

Grails dynamic finders

def persons = Person.findByLastName('Stark')
assert persons.findAll {
   it.alive
}.isEmpty()

Gradle task execution

task(hello) << {
    println "hello"
}

vs

task(hello) {
    println "hello"
}

Some thoughts

  • removing semicolons is not designing a DSL

  • removing parenthesis is not designing a DSL

  • user experience is important

  • consistency is important

  • Try to be idiomatic

Modern Apache Groovy DSLs

Spock

given:
def shell = new GroovyShell()

when:
def sum = shell.evaluate("""
            @groovyx.ast.bytecode.Bytecode
            int sum(int limit) {
               l0:
                iconst_0
                istore 2
               ...
        """)

then:
sum(i) == reference
where:
i   |   reference
0   |   0
1   |   0
2   |   1
3   |   3
4   |   6

Grails 3 where queries

assert Person.findAll {
   lastName == 'Stark' && alive
}.isEmpty()

Gradle new model

model {
    components {
        main(JvmLibrarySpec) {
            sources {
                java {
                    dependencies {
                        library 'myLib'
                    }
                }
            }
            targetPlatform 'java8'
        }
        myLib(JvmLibrarySpec) {
            api {
                exports 'my.package'
            }
            targetPlatform 'java5'
            targetPlatform 'java6'
        }
    }
}

Ratpack

ratpack {
    handlers {
        get {
            render "Hello World!"
        }
        get(":name") {
            render "Hello $pathTokens.name!"
        }
    }
}

Jenkins Job DSL

job {
    using 'TMPL-test'
    name 'PROJ-integ-tests'
    scm {
        git(gitUrl)
    }
    triggers {
        cron('15 1,13 * * *')
    }
    steps {
        maven('-e clean integTest')
    }
}

MarkupTemplateEngine

modelTypes = {
   List<String> persons
}

html {
    body {
        ul {
            persons.each { p ->
                li p.name
            }
        }
    }
}

Implementing modern DSLs

The tools

  • Closures with support annotations (@DelegatesTo, …​)

  • Compilation customizers

  • AST transformations

  • Type checking extensions

  • Groovy Shell / Groovy Console

Closures

  • Still at the core of most DSLs

  • delegate is very important:

['Paris', 'Washington', 'Berlin'].collect {
   it.length() == 5
}
  • do we really need it?

Setting the delegate

class  HelperExtension {
    public static <T,U> List<U> myCollect(
       List<T> items,
       Closure<U> action) {
       def clone = action.clone()
       clone.resolveStrategy = Closure.DELEGATE_FIRST
       def result = []
       items.each {
           clone.delegate = it
           result << clone()
       }
       result
    }
}

HelperExtension.myCollect(['Paris', 'Washington', 'Berlin']) {
    length() == 5
}

Convert it to an extension module

  • META-INF

    • services

      • org.codehaus.groovy.runtime.ExtensionModule

moduleName=My extension module
moduleVersion=1.0
extensionClasses=path.to.HelperExtension

Convert it to an extension module

  • Consume it as if it was a regular Groovy method

['Paris', 'Washington', 'Berlin'].myCollect {
    length() == 5
}

Declare the delegate type

  • Best IDE support

  • Only way to have static type checking

public static <T,U> List<U> myCollect(
    List<T> items,
    @DelegatesTo(FirstParam.FirstGenericType)
    Closure<U> action) {
...
}

Removing ceremony

  • Is your DSL self-contained?

  • If so

    • Embrace SAM types

    • Try to remove explicit imports

    • Avoid usage of the new keyword

    • Avoid usage of annotations

SAM what?

This is ugly:

serve(new Handler() {
    @Override
    void handle(String message) {
       println message
    }
})

SAM what?

This is cool:

serve {
   println message
}

SAM type coercion works for both interfaces and abstract classes.

Compilation customizers

class WebServer {
   static void serve(@DelegatesTo(ServerSpec) Closure cl) {
       // ...
   }
}

Compilation customizers

def importCustomizer = new ImportCustomizer()
importCustomizer.addStaticStars 'com.acme.WebServer'

def configuration = new CompilerConfiguration()
configuration.addCompilationCustomizers(importCustomizer)

def shell = new GroovyShell(configuration)
shell.evaluate '''
serve {
   port 80
   get('/foo') { ... }
}
'''

Compilation customizers

  • ImportCustomizer: automatically add imports to your scripts

  • ASTTransformationCustomizer: automatically apply AST transformations to your scripts

  • SecureASTCustomizer: restrict the grammar of the language

  • SourceAwareCustomizer: apply customizers based on the source file

  • See docs for customizers

Type checking extensions

Goals

  • Provide early feedback to the user

  • Type safety

  • Help the compiler understand your DSL

Type checking extensions API

  • Event-based API

  • React to events such as undefined variable or method not found

  • Developer instructs the type checker what to do

methodNotFound { receiver, name, argList, argTypes, call ->
    if (receiver==classNodeFor(String)
            && name=='longueur'
            && argList.size()==0) {
        handled = true
        return newMethod('longueur', classNodeFor(String))
    }
}

Type checking extensions

  • Powerful tool but focused on the Groovy compiler

  • See documentation

MarkupTemplateEngine example

  • Given the following template

pages.each { page ->
    p("Page title: $page.title")
    p(page.text)
}
  • How do you make sure that pages is a valid model type?

  • How do you notify the user that page doesn’t have a text property?

  • How to make it fast?

Solution

  • Declare the model types

modelTypes = {
    List<Page> pages
}

pages.each { page ->
    p("Page title: $page.title")
    p(page.text)
}
  • Implement a type checking extension

MarkupTemplateEngine extension

  • Recognizes unresolved method calls

    • converts them into direct methodMissing calls

  • Recognizes unresolved variables

    • checks if they are defined in the binding

    • if yes, instructs the type checker what the type is

MarkupTemplateEngine extension

  • Applies @CompileStatic transparently

  • Performs post-type checking transformations

    • Don’t do this at home!

(Optional) @ClosureParams

  • For type checking/static compilation

['a','b','c'].eachWithIndex { str, idx ->
  ...
}

(Optional) @ClosureParams

public static <T> Collection<T> eachWithIndex(
   Collection<T> self,
   @ClosureParams(value=FromString.class, options="T,Integer")
   Closure closure) {
   ...
}

Check out the documentation for more details.

What we learnt

  • Leverage the lean syntax of Groovy

  • Scoping improves readability

  • Use the delegate

  • Use @DelegatesTo and @ClosureParams for IDE/type checker support

  • Use imperative style as last resort

  • Help yourself (builders, specs vs impl, …​)

Questions

qa

We’re hiring!

GradleLogoLarge

Thank you!
